eta Pellets Compact - Check the Combustion Chamber; Checking the Firebed Lever and Firebed Switch

Cleaning and maintenance Maintenance (expert)
25
2.6.6 Check the combustion chamber
Removing the maintenance cover for the
combustion chamber
Open the boiler door.
Fig. 2-44: Boiler door
Remove the nuts on the maintenance cover and
carefully remove it too.
Fig. 2-45: Maintenance cover
Removing the combustion chamber cover
Remove the combustion chamber cover from the
combustion chamber with the poker.
Fig. 2-46: Combustion chamber cover
Checking the firebed lever and firebed switch
Check the movement of the firebed lever in the
combustion chamber by repeated lifting.
Fig. 2-47: Firebed lever
The firebed switch must be actuated when lifting.
Fig. 2-48: Firebed switch
