2.6.11 Check ash box position switch
Checking the ash box position switch
Check the function of the position switch for the ash
box. It must be actuated when the ash box is attached.
Fig. 2-69: Position switch for ash box
2.6.12 Attaching panels
Installing the side covers
Re-install the side covers.
Fig. 2-70: Side cover
Mounting the cover on the front
Re-install the cover back on the front of the boiler.
Fig. 2-71: Cover
