ETC Installation Guide
ColorSource Spot v1.7
Note:
The light source in this luminaire is not user-replaceable, and
must be replaced only by a qualified technician. Contact ETC
Customer Support for assistance.
Environment
The ColorSource Spot operates in ambient temperatures of 0°C–40°C and
comes with a variable-speed fan. The ColorSourceSpot is for indoor use only.
Maximum recommended ambient operating temperature: Ta=40°C
(104°F)
Maximum anticipated external surface temperature at 40°C ambient:
Tmax = 80°C (176°F)
External temperatures after 5 minutes of full-brightness operation at
25°C (77°F) ambient: 30°C (86°F)
External Temperature (steady state achieved) at 25°C (77°F): 36°C
(97°F)
Electrical
Operates between 100V and 240VAC at a frequency of 50/60Hz.
Maximum power consumption is 185 W.
Up to 9 luminaires(15 A max) may be linked via power thru connector
(10 luminaires total per circuit) when used with an R20Relay Module
or Unison Echo Relay Panel. Consult breaker trip curves when used
with other equipment. Requires power from a non-dimmable source.
Inrush:
120 V: 28 A (first half-cycle)
240 V: 46 A (first half-cycle)
Typical Power Consumption
100 V 120 V 230 V
Power Current Power Current Power Current
Idle 1.19 W 0.05 A 2.07 W 0.05 A 1.5 W 0.05 A
Direct at Full 168 W 1.69 A 166 W 1.39 A 166 W 0.72 A
ColorSource Spot Page 3 of 12 ETC
