SPECIFICATIONS
GENERAL
• 60 LED array
• ETL listed to UL1573 – the standard for stage and studio
lighting units
• IP20-rated for indoor use
• Power and DMX in/thru connections for easy setup
• User-friendly control interface with multiple modes and
fixture settings
PHYSICAL
• Rugged die-cast all-metal housing
• Available in black (standard), white or silver (optional) or
custom colors (contact factory)
• C-clamp
• Positive locking Double-clutch fixture body
• Slot for glass or stainless steel patterns and Soft Focus Diffuser
• Wide accessory slot with sliding cover for motorized pattern
devices or optional iris
• Hanging yoke standard. Optional yoke/floor stand available
ELECTRICAL
• 100VAC to 240VAC 50/60 Hz universal power input
• Neutrik power in and thru connections
• Up to 9 fixtures (15A max) may be linked via power thru
connector
• Requires power from a non-dim source
LED*
• 50,000 hour LED life (50,000 hours to 70% intensity)
• 60 2.5W LED emmitters
*See additional LED notes on page three
COLOR
• Provides rich variable white light
• Color temperature range from 2700K-6500K
• Broad-spectrum color interacts seamlessly with
conventional sources
• Exclusive optional red-shift option emulates incandecent
dimming performance
• Beautifully illuminates skin tones and other objects for natural
appearance and high color rendering
• Also available with Lustr+, Daylight, or Tungsten LED arrays
OPTICAL
• Use the included soft-focus diffuser for creating washes or
soft light
• Best performance using ETC’s EDLT lens tubes
• Can use all ETC Source Four Interchangeable lens barrels: 5°,
10°, 14°, 19°, 26°, 36°, 50°, 70°, and 90° field angles as well
as 19°, 26°, 36°, and 50° EDLT lenses
• For better performance use the new LED 50° barrel
CONTROL
• DMX512 in and thru via five-pin XLR connectors
• Multiple control options including RGB, strobe, and console-
free Master/Slave mode
• See DMX Control Table for additional information
• 15-bit virtual dimming engine provides smooth, high quality
theatrical fades and minimizes color shift during dimming
• RDM functionality for address and setting changes
ETC
®
Source Four LED Series
Source Four LED
™
SPECIFICATIONS
THERMAL
• Ambient operating temperature of -4° to 104°F (-20° to 40°C)
• Active electronic thermal management for
droop-free operation
• Quiet fan cooling
• Fixture is designed for continuous operation up to 104°F
(40°C) ambient temperature and requires free flow of air
around fixture housing
ADDITIONAL ORDERING INFORMATION
Power Input Cables
Use information below to order 5’ power input leads with factory fitted connectors
MODEL DESCRIPTION
DPA-A
5’ PowerCon
™
to parallel blade U-ground
(Edison) connector
DPA-B
5’ PowerCon to 20A two pin and ground
(stage pin) connector
DPA-C 5’ PowerCon to grounded 20A twistlock connector
DPA-X 5’ PowerCon to bare-end power input lead
Power Thru Jumpers
Note: Power thru jumpers connect to fixture’s output (thru) connector to provide link
to successive fixtures
MODEL DESCRIPTION
DPJ-5
5’ PowerCon to PowerCon
™
fixture to
fixture jumper
DPJ-10
10’ PowerCon to PowerCon
fixture to
fixture jumper
Diffusers
MODEL DESCRIPTION
S4LED-SFD Source Four LED—Soft Focus Diffuser (included)
S4LED-SFDI
Source Four LED—Souf Focus Diffuser Permanent
Installation Kit
S4LED-SWD6
Source Four LED—Smooth Wash Diffuser for 6.25
gel frame slots
S4LED-SWD7
Source Four LED—Smooth Wash Diffuser for 7.5
gel frame slots
S4LED-SWD12
Source Four LED—Smooth Wash Diffuser for 10°
lens tubes
S4LED-SWD14
Source Four LED—Smooth Wash Diffuser for 5°
lens tubes
The Soft Focus Diffuser fits into a standard A-Size pattern holder and delivers
beautiful homogenized light when not in sharp focus. Also, use with patterns for
dappled and soft edge projections.
The Smooth Wash Diffuser is used when extra-smooth blending of multiple Source
Four LED fixtures is required. The smooth wash diffuser is placed into the gel frame
slot of the lens tube.
