H124DN - H124DX - H124DL
2845
1158
3073
1280
9
DIRECTION INDICATOR
<= Left direction indication
=> Right direction indication
ALARM
HAZARD WARNING
SIGNALLING
Left side : Flashing light switched on
Right side : Flashing light and lighting switched on
Note : There is no flashing light on the H124DL
DIPPED HEADLIGHTS
ENGINE PRE-HEATING WARNING LIGHT
ENGINE OIL PRESSURE INDICATOR
TEMPERATURE INDICATOR OF COOLING
LIQUID
A buzzer is associated with it.
BATTERY CHARGE INDICATOR
HYDRAULIC OIL TEMPERATURE INDICATOR
AND CLOGGING OF HYDRAULIC FILTER
FUEL GAUGE
2• KEY TO DIAGRAMS - USE
