ETS-Lindgren 2188 - 6 Assembly and Installation; Required Tools

Assembly and Installation | 21
6.0 Assembly and Installation
Before connecting any components, follow the safety information
in the ETS-Lindgren Product Information Bulletin included with
your shipment.
Prior to assembly and installation, review the drawings located in the back
pocket of this manual.
Proper installation of the turntable directly affects performance. The installation of
turntables two meters and larger will be performed by factory installation
specialists or individuals authorized by ETS-Lindgren to perform such work. The
following information is included only to provide an informational overview of the
installation process.
Required Tools
 3/16-in Allen wrench  3/4-in pipe clamp ends
 1/4-in Allen wrench
 3/4-in pipe (about 6 feet;
length depends on turntable size)
 3/8-in Allen wrench (3)  1 1/2-in C clamp (8)
 6-mm Allen wrench  Measuring tape
 3/8-in ratchet wrench  Pry bar
 12-in crescent wrench  Level
 15-mm, 12-point socket for
1/2-in square head screws
 Square
 7/16-in open/box end wrench  Hacksaw
 1/2-in open/box end wrench  Black marker
 3/4-in open/box end wrench  File
 0.120 drill bit for 6–32 self-tapping
screws
 WD-40®
 #7 drill bit for 1/4–20 tap  Cutting oil
