28 | Assembly and Installation
3. Attach the chain around the bearing sprocket and the drive sprocket.
Adjust the motor base using the two pusher bolts provided. Allow only
1/4-in maximum side-to-side motion for proper chain tension on the
motor.
4. Tighten the six securing bolts.
Post Installation Steps
FINAL LEVEL OF TURNTABLE
Once the turntable is in place with the floor flange and wear strip mounted, check
that the table is level. Verify that it is level and all screws, nuts, and collars are
tightened.
CONDUCTIVE GREASE APPLICATION
Before placing the turntable into operation, apply conductive grease to the
ground brush. Apply the contents of one tube of conductive grease to the brush.
Apply one tube per meter size of the diameter of the turntable.
