Operation | 29
7.0 Operation
Before placing into operation, follow the safety information in the
ETS-Lindgren Product Information Bulletin included with your
shipment.
EMCenter Modular RF Platform
With the assembly of the turntable complete, the EMCenter Modular RF Platform
(or next generation ETS Lindgren controller, if applicable) must be connected to
the unit and power applied to both the motor base and controller. See the
controller manual for complete information on connecting the fiber optic cable
and operating the controller. A manual is available for download from
ets-lindgren.com.
Note: If you are unfamiliar with the operation of the EMCenter, see the
manual, available for download from
ets-lindgren.com.
The EMCenter replaces the 2090 Controller, which has been discontinued.
The 2090 requires firmware revision V 3.21 or higher. It is available for
download at ets-lindgren.com and requires the program Flash Upgrade
Wizard V 4.0 (also available at ets-lindgren.com).
Motor Base Status Indicators
Following are actions of the status indicators when used with the Infrared
Remote Controller (IR remote). For more information on the IR remote, see
page 8.
State 1 2 3 4
Power
Any Any Any Any
Init
Cycling Amber
Up/CW
Green
Down/CCW
Green
Polar
Green
Upper Limit
Red
Lower Limit
Red
