10
Corresponds to EC directives
Corresponds to the requirements of § 21 of the
German Product Safety Law
Insulated housing (protection class II).
Devices with this symbol may only be operated
indoors (dry environment)
Image 1: Front view Image 2: Rear view Image 3: View right
Read the operating instructions
Polarity of the plug connector
Labelled electrical products may not be
disposed of in the household waste
Labelling according to § 17 BattG (German battery
laws): The end consumer is obliged to send batte-
ries to the dealer for proper disposal or to hand in
at an appropriate collection point.
5. Explanation of symbols
6. Operating instructions
6.1 Overview
1 Charging socket 9 Manometer
2 Charging indicator light 10 ON/OFF switch for compressor
3 LED working light 11 Storage compartment cover for air hose
4 Black pole calliper (-) 12 12 V socket
5 Red pole calliper (+) 13 Plug charger
6 Charge status display 14 Motor vehicle charging cable
7 Switch for LED working light 15 Valve adapter
8 Push button for charge status display
Image 4: Accessories
