Email：support@euhomy.com
Facebook：@Euhomy.Official
Ice Maker
SKU：IM-FP
Instruction Manual

Table of Contents

Questions and Answers

  • J
    jbeasleyAug 15, 2025
    Why is the 'add water' indicator on my Euhomy Ice Maker?
    • M
      Mark OlsonAug 15, 2025
      The 'add water' indicator turns on due to several reasons: * There is no water supply. Check the main water supply pressure and the water supply hose for blockages. Increase water pressure or clean the hose as needed. * The floating ball of the water level detecting switch is blocked. Clean the water tank and the water level detecting switch. * Water flows out from the water tank. Ensure the unit is on a level surface. * Water flows out from the water drainpipe. Pull out the pipe and reinstall it properly into the slot of the water tank.
  • E
    Eric AshleyAug 18, 2025
    Why is my Euhomy Ice Maker not producing ice, even though the cycle seems normal?
    • A
      andersonangelaAug 18, 2025
      If the ice making cycle is normal, but no ice is produced, the ambient temperature or the water temperature in the tank might be too high. Move the unit to a place where the temperature is below 90°F (32°C) and use low-temperature water. Other potential causes include refrigerant leakage or a clogged cooling system tube, both of which require a qualified technician to address.
  • J
    Joseph SmithAug 22, 2025
    What to do if my Euhomy Ice Maker starts making ice but no water flows in and the 'add water' indicator flashes?
    • E
      Edward LozanoAug 22, 2025
      If the unit starts to enter the ice making process, but no water flows in the unit, and the 'add water' indicator flashes, it indicates a water supply issue. Check the main water supply pressure and ensure the water supply hose isn't blocked. Increase the water pressure or clean the hose if necessary.
  • A
    Alexandra CastilloAug 25, 2025
    What to do if my Euhomy Ice Maker's water pump is working, but no water flows out from the water dividing pipe?
    • K
      kristenchristensenAug 26, 2025
      If the water pump is working, but no water flows out from the water dividing pipe, it's likely that the small holes on the water dividing pipe are blocked. Clean these holes to restore water flow.
  • E
    esmithAug 28, 2025
    Why is the 'ice full' indicator on my Euhomy Ice Maker?
    • K
      kyle03Aug 28, 2025
      The 'ice full' indicator illuminates when the ice storage bin is full. Simply remove some ice cubes to resolve this.
  • A
    Andrea MillerAug 31, 2025
    Why Euhomy IM-FP Ice Maker ice cube shape is irregular?
    • K
      Karen PorterAug 31, 2025
      The ice cube shape may be irregular if the water quality is not good, or the water tank is very dirty, or the little holes on the water dividing pipe is some blocked. Water supplying hose breakdown, or water flows in very slowly. The little holes on the water dividing pipe is blocked.
  • R
    rcarrSep 4, 2025
    Why are the ice cubes from my Euhomy IM-FP not transparent?
    • J
      John AdamsSep 4, 2025
      If the ice cubes aren't very transparent, it could be due to poor water quality. Try changing the water supply or using a water filter to soften or filter the water.
  • S
    smithmelissaSep 7, 2025
    Why is my Euhomy IM-FP making very thin ice cubes?
    • J
      Julie LawrenceSep 7, 2025
      Very thin ice cubes can result from a high ambient temperature or poor air circulation around the unit. Water quality is bad.
  • H
    Henry Weeks MDSep 12, 2025
    Why are the ice cubes from my Euhomy IM-FP too thick?
    • D
      donaldrobinsonSep 12, 2025
      If the ice cubes are too thick, the ambient temperature might be too low. Try reducing the time of each ice making cycle.

Summary

Safety Precautions

Operation & Installation

Assembly and Parts Overview

Details about the control panel, indicators, and physical components of the ice maker.

Unpacking Your Ice Maker

Instructions for removing packaging, cleaning interior parts, and initial placement.

Connecting Your Ice Maker

Guidance on electrical connection, grounding, and outlet requirements for safe operation.

Operation Panel and Display Area

Explanation of the control panel functions, display indicators, and ice making process.

Automatic Self-Cleaning Program

Steps to initiate and manage the automatic self-cleaning cycle for the ice maker.

Canceling the Self-Cleaning Program

How to stop the self-cleaning cycle prematurely if needed.

Tips & Maintenance

Cleaning and Maintaining Your Ice Maker

Detailed instructions for thorough cleaning of the ice maker's interior and exterior parts.

Specifications

Technical Parameters

Key specifications including SKU, climate type, power, refrigerant, and weight.

Circuit Diagram

Electrical schematic illustrating the internal components and connections of the ice maker.

Warranty Information

Troubleshooting Guide

Euhomy IM-FP Specifications

General IconGeneral
Ice TypeBullet
Ice Making Capacity26 lbs per day
Ice SizeSmall, Large
Noise Level≤45 dB
Voltage115V/60Hz
