2.2 Description of the control module
The following drawing illustrates the aspect of the EVF815 control module.
The following table illustrates the meaning of EVF815 control module parts.
Part Meaning
1 serial port with MODBUS communication protocol
2 communication port with the user interface (signal and power supply)
For further information, see the next chapters.
