13 ACCESSORIES
13.1 EVKEY programming key
13.1.1 Introduction
EVKEY is a programming key.
The key can be used to upload and download the configuration parameters.
The key can be used on condition that the device is powered.
13.1.2 Description
The following drawing illustrates the aspect of the EVKEY.
The following table illustrates the meaning of the EVKEY parts.
Part Meaning
1 reserved
2 Signal LED
3 Micromatch connector
4 programming key
