Evco EVJ LCD - Output Status

EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 62 of 72
S71 %
Return fan analogue output value
-1 = Disabled
RO
S72 %
Water valve analogue output value
-1 = Disabled
RO
S73 %
Mixing chamber damper analogue output value
-1 = Disabled
RO
S74 %
Heater analogue output value
-1 = Disabled
RO
S75 %
Heater TK/OC output value
-1 = Disabled
RO
S76
Supply fan digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S77
Return fan digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S78
Compressor digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S79
Reversing valve digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S80
Rotary recovery heat exchanger/bypass damper digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S81
External air damper digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S82
Open water valve digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S83
Close water valve digital output value
Disabled =-1
OFF = 0
ON =1
RO
S84
Step 1 heater digital output value
-1 = Disabled
0 = OFF
1 = ON
RO
S85
Step 2 heater digital output value
-1 = Disabled
0 = OFF
RO
