• If installing the convenience base with a vehicle seat
belt, return to page 18, Step 2.
• If installing the carrier (no convenience base) with a
vehicle seat belt, return to page 25, Step 4.
1/2 in. (13 mm)
Ô
Ô
Remove locking clip from vehicle seat belt when
not used with a child restraint, or the vehicle seat
belt will not properly restrain an adult or child.
Serious injury could occur.
WARNING
4
5
34 35
To watch a video about installing a locking clip, go to
www.evenflo.com.
Thread the seat
belt B through the
base C (or child
restraint) and
buckle the seat belt.
Push down on the
base C while pulling
the shoulder belt D
tightly to remove all
slack from the lap
portion of the belt.
D
Hold the lap and
shoulder belts together
just behind the free
sliding buckle
tongue
E and
unbuckle the seat belt.
While holding the belts
and buckle tongue E,
thread the locking
clip E onto the seat
belt, and slide it into
place.
Note: Locking clip
must be placed within
1/2 in. (13 mm) of
seat belt buckle.
Using the Locking Clip
1
2
3
B
E
E
E
E
Some ELR vehicle belts can be
switch so that they lock when
tightened.
Use the locking clip with:
Lap/shoulder seat belt
combination that has a buckle
tongue that slides freely along the
belt without locking into place A
and is equipped with an
emergency locking retractor (ELR).
Consult your vehicle owner’s manual before
installing the locking clip.
Locking Clip
A
E
Buckle the seat belt
with the locking
clip E in place.
To Next Page
