More children are killed every year as passen-
gers in car crashes than by any other type of
injury. To reduce the risk of SERIOUS INJURY or
DEATH, read this owner’s manual and your vehicle
owner’s manual before installing and using this child
restraint. Using a child restraint makes a big difference.
By properly using this child restraint and following
these instructions (and the instructions that accompany
your vehicle), you will greatly reduce the risk of serious
injury or death to your child from a crash. Do not be
misled by the commonly used term “safety seat”; no
restraint system can prevent all injuries in all crashes.
Many properly restrained adults and children are
injured in motor vehicle crashes, including relatively
minor crashes. A properly used child restraint is the best
way to minimize injuries to your child and to increase
the chances for your child’s survival in most crashes.
Table of Contents
Rear-facing Use ONLY
Weight: 5 – 22 lbs (2.3 – 10 kg)
Height: 19 – 29 inches (48 – 74 cm)
Top of the child’s head must be at least 1 inch
(25 mm) below the top of the child restraint seat back.
1
• IMPORTANT •
This child restraint meets all the requirements of Federal
Motor Vehicle Safety Standard 213. No child restraint
can guarantee absolute protection from injury in every
crash.
This child restraint is designed for use
ONLY in the rear-
facing position by children who weigh between 5 and
22 lbs (2.3 kg and 10 kg) and whose height is between
19 and 29 inches (48 to 74 cm).
NEVER use this child restraint
in the forward-facing position.
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safe Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Recall Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Airplane Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
LATCH Information . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Visual Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the Discovery Handle . . . . . . . . . . . . . . . . . . . .12
Proper Installation WITH the Base . . . . . . . . . . . . . .14
Installing the Base with the LATCH System . . . . . . . . . .16
Installing the Base with the Vehicle Seat Belt . . . . . . . .18
Releasing the Carrier from the Base . . . . . . . . . . . . . . .21
Proper Installation WITHOUT the Base . . . . . . . . . .22
Installing the Carrier without the Base . . . . . . . . . . . . .24
Securing the Child in the Carrier . . . . . . . . . . . . . . . .27
Removing the Child from the Carrier . . . . . . . . . . . . .29
Changing the Harness Position . . . . . . . . . . . . . . . . . .30
Changing the Crotch Strap Position . . . . . . . . . . . . . .22
Removing the LATCH System . . . . . . . . . . . . . . . . . . .33
Using the Locking Clip . . . . . . . . . . . . . . . . . . . . . . . .34
Using as an Infant Carrier . . . . . . . . . . . . . . . . . . . . . .36
Canopy Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Harness straps at, or
below, the shoulder.
At least 1 inch
(25 mm)
