28
ALWAYS store the tether strap (pg. 71). Never use tether
strap when child restraint seat is rear-facing.
1. Make sure vehicle is on level ground.
2. Place child restraint rear-facing on approved vehicle
seat. Always make sure the bottom of the child
restraint sits flat on the vehicle seat.
3. Remove Lower Anchor Connectors from sides of the
seat (pg. 24). CHECK Lower Anchor strap is in rear-
facing belt path (pg. 27).
4. Lift up on the
recline handle as
shown and adjust
the seat to one of
the three rear-
facing recline
positions, so
that the level
line is parallel
to the ground.
IMPORTANT: Infants may have difficulty breathing
when in an upright seated position. Make sure they
recline enough for their head to lie back comfortably
and safely. Failure to properly recline the child restraint
could increase the child’s risk of serious injury or death.
5. Ensure child restraint is secure using the appropriate
connector on pages 29 - 31, then continue with Steps
6 - 8 on pg. 32.
Rear-facing Installation with Lower
Anchor (UAS) Connectors
Shoulder
straps must
be at or just
below child’s
shoulders
1,8 - 18,1 kg (4 - 40 lbs)
43 - 102 cm (17 - 40 in)
MUST be level with
ground with Rear Facing
installations
REAR FACING LINE
Top of head
MUST be 2.5 cm
(1 in.) or more
below top of
headrest or shell
Chest clip
25808432 8/19
Lap Shoulder Belt
LATCH / UAS
Lap Belt
Route shoulder belt
only through lock off.
See user manual for
additional information.
LOCK OFF
REAR FACING
BELT PATH
