38
Forward-facing
Belt Path
Tether
Strap
Lower
Connector
(UAS)
Assembly
Child Requirements:
• Weight: 10 - 29.5 kg (22 - 65 lbs)
• Height: 71 - 124 cm (28 - 49 in.) and
tops of child’s ears are at or below the
top of the child restraint headrest.
• Age: At least 2 years old
IMPORTANT: ALWAYS USE THE TOP ANCHORAGE
(TETHER) STRAP.
Harness straps
are AT or JUST
ABOVE the
child’s shoulders.
Lower Anchor
Connector (UAS)
Assembly
DO NOT install by
this method for a
child weighing more
than 18 kg (40 lbs).
Using the Child Restraint
Forward-facing with Harness
IMPORTANT: Once your child exceeds any of the size
requirements for forward-facing with harness use
above, and is at least 4 years old, you MUST discontinue use
of this child restraint with its internal harness and begin using
it in booster mode.
