26
Child Requirements:
• Weight: 1.8 - 18.1 kg (4 - 40 lbs)
• Height: 43 - 102 cm (17 - 40 in.) and
top of child’s head is at least 2.5 cm
(1 in.) or more below the top of child
restraint headrest
IMPORTANT: Once your child exceeds any of the size
requirements above, they MUST use this child restraint
in the forward-facing orientation, if possible. If your
child exceeds any of the size requirements above and
is less than 2 years old, however, you MUST discontinue
use of this child restraint.
When using this restraint rear-facing, DO NOT loosen
the vehicle seat belt to provide more leg room as this
may keep the child restraint from protecting your child.
2.5 cm (1 in.) or more
Harness straps
are AT or JUST
BELOW the child’s
shoulders.
Rear-facing
Belt Path
Lower
Anchor (UAS)
Connector
Assembly
Using the Child Restraint
Rear-facing
WARNING!
DEATH or SERIOUS
INJURY can occur.
To Next Page
