25
To store the lower anchor (UAS) connector, push
UNTIL it clicks into position as shown below:
Rear-Facing
Forward-Facing
4
5
3
2
1
CLICK!
Child Restraint Features
Important
Shoulder
straps must
be at or just
below child’s
shoulders
1,8 - 18,1 kg (4 - 40 lbs)
43 - 102 cm (17 - 40 in)
MUST be level with
ground with Rear Facing
installations
REAR FACING LINE
Top of head
MUST be 2.5 cm
(1 in.) or more
below top of
headrest or shell
Chest clip
25808432 8/19
Lap Shoulder Belt
LATCH / UAS
Lap Belt
Route shoulder belt
only through lock off.
See user manual for
additional information.
LOCK OFF
REAR FACING
BELT PATH
CLICK!
4
5
3
2
1
B: Press the adjuster release
button to loosen.
A: Tilt and slide the
adjuster to loosen.
If you have Quick Connector™ or SecureRight™, loosen
the lower anchors as shown below:
Loosen Lower Anchor (UAS) Connectors
Store Lower Anchor (UAS) Connectors
A
B
