Which Type of Lower Anchor
Connector Is on Your Child Restraint?
Your child restraint will have one of the three types of
Lower Anchor Connectors (shown below):
1. EasyClick™
2. Quick Connector™ with LATCH/UAS Guide*
3. SecureRight™
Follow the instructions on the following pages to
properly install the Lower Anchor Connector Assembly
on your child restraint.
To remove the lower anchor (UAS) connector from
its storage location, pull the red Release Strap. For
SecureRight™, push in, squeeze, and twist to remove.
Forward-facing lower
anchor (UAS) storage
Shoulder
straps must
be at or just
below child’s
shoulders
1,8 - 18,1 kg (4 - 40 lbs)
43 - 102 cm (17 - 40 in)
MUST be level with
ground with Rear Facing
installations
REAR FACING LINE
Top of head
MUST be 2.5 cm
(1 in.) or more
below top of
headrest or shell
Chest clip
25808432 8/19
Lap Shoulder Belt
LATCH / UAS
Lap Belt
Route shoulder belt
only through lock off.
See user manual for
additional information.
LOCK OFF
REAR FACING
BELT PATH
Rear-facing lower anchor
(UAS) storage
Child Restraint Features
Lower Anchor Connector (UAS)
Release
Strap
Quick Connector™
with LATCH/UAS
Guide
Release
Strap
EasyClick™
SecureRight™
* Guides not available on all models.
Remove Lower Anchor (UAS) Connectors
To Next Page
