40
DO NOT install by this method for a child weighing
more than 18 kg (40 lbs).
Infants who weigh less than 10 kg (22 lbs) MUST always
be rear-facing.
If a tether anchor is not available, ALWAYS store the
Tether Strap (pg. 71).
1. Remove Lower Anchor Connectors from storage
location (pg. 24). MAKE SURE Lower Anchor strap
is in forward-facing belt path (pg. 39).
2. Lift up on the
recline handle
as shown and
adjust the
seat recline to
the upright
position.
3. Place child restraint in your vehicle forward-
facing, as shown. Always make sure the bottom of
the child restraint sits flat on the vehicle seat.
4. Unhook tether strap
from the rear of the
child restraint and
place tether hook with
red adjuster (pg. 71)
over back of vehicle
seat.
5. Ensure child restraint
is secure using the
appropriate connector
on pages 41 - 43, then
continue with Steps
6 - 8 on pages 43 - 45.
Tether
Strap
PLACE
AT
ARMPIT
Forward-facing Installation with
Lower Anchor (UAS) Connectors
To Next Page
