42
Install the LATCH/UAS Guides*
NEVER use if parts are broken or damaged.
NEVER use LATCH/UAS Guides if they interfere in any
way with installation.
Connect one guide,
if provided, to each
lower anchor by
sliding the guide
into the vehicle seat
crease and under
the lower anchor.
Install the Quick Connectors™
Attach lower anchor / UAS
connectors to the vehicle
lower anchor bars until they
lock onto the bars on both
sides of the seat.
Using your full weight, push
the child restraint firmly into
the vehicle seat while pulling
up on the Lower Anchor
Strap to tighten and remove
all slack, as shown.
CLICK!
Correct
Incorrect
Quick Connector™
Forward-facing Installation with
Lower Anchor (UAS) Connectors
Restraints with Quick Connectors™
WARNING!
DEATH or SERIOUS
INJURY can occur.
IMPORTANT: Make
sure both lower anchor
connectors are facing
upward and the straps
are not twisted.
* Guides not available on all models.
