Forward-Facing
49
Raise headrest to its highest
position (pg. 65), then lift
headrest pad away from child
restraint for easier access. Route
the lap/shoulder belt through
the forward-facing belt path
and continue through the
opposite opening of the child
restraint. Fasten the buckle.
IMPORTANT: Make sure
the lap/shoulder belt lies flat
without twisting.
The vehicle seat belt must
be as tight as possible. Using
your full weight, push the child
restraint firmly into the vehicle
seat as you tighten the vehicle
seat belt, as shown. Lower the
headrest pad.
Insert the shoulder belt
into the forward-facing
lock-off on the side of
the restraint opposite
the seat belt buckle. The
shoulder belt MUST be routed
through the lock-off. If vehicle
permits, the retractor must be
locked (pg. 12).
Check your work. Pull on
the belt to make sure it's tight
and locked. If you can move the child restraint more than
2.5 cm (1 in.) side to side or front to back at the forward-
facing belt path, the vehicle belt is not tight enough. If you
have not tightly secured the child restraint, try again, move
it to another location, or install with the lower anchor
connector assembly (pg. 40).
Continue with Step 5 (pg. 51) to attach tether strap.
PLACE
AT
ARMPIT
Forward-facing with Lap/Shoulder Belt
Forward-facing Installation with
Vehicle Seat Belts
Lap/Shoulder
belt
Headrest
pad
CLICK!
