22
Refer to your owner’s manual to locate the lower
anchors on your vehicle seat.
Attach the right hook B to the right anchor C and
the left hook to the left anchor. DOUBLE CHECK that
the hooks are fully engaged by pulling hard on each
side of the LATCH harness.
3
B
4
Using your full weight,
push the base firmly into
the vehicle seat, while
pulling up on the strap to
tighten.
Make sure the LATCH har-
ness is tight. Grab the base
at the areas D, as shown.
If you can move the base
more than 25 mm (1 inch)
forward or side-to-side, the
A
5
harness is not tight enough. You will need to try again or
find another location for your convenience base.
IMPORTANT
Route any excess LATCH harness strap through the
openings A on the sides of the base so it does not inter-
fere with the metal carrier retainers E when attaching
the carrier.
D
E
WARNING
C
Ö
