27
Shoulder harness straps on this child restraint are ad-
justable to four positions.
Rear facing, the shoulder harness straps should
ALWAYS start at or below the child’s shoulders in one
of the three lower harness positions A or B and the
child’s head MUST be at least 25 mm (1 inch) below
the top of the seat back.
Forward-facing, you MUST use one of the top two
harness positions B or C. If the tops of the child’s
ears are above the top of the seat back, the child’s
shoulders fall above the upper harness slots, or the
child weighs more than 22.6 kg (50 lbs), you MUST
discontinue use of this child restraint. We recommend
that you move your child to a larger child restraint or
booster seat.
Forward- OR
Rear-facing
Middle Harness Position
B
Positioning the Harness Strap
Forward-facing ONLY
Top Harness Position
C
Rear-facing ONLY
Bottom Two
Harness Positions
A
