12.1 Head Compartment and Berth
The head compartment is equipped with a fresh
water sink and faucet that converts to a shower by
pulling the faucet out of the base. An acrylic panel
folds down above the marine toilet to provide a
seat while showering. The panel is held in the up
position by a magnetic latch. Always make sure
the panel is in the down position when the toilet
is not being used and before operating the boat.
Shower water drains to the sump system where
it is pumped overboard. A oat switch in the
sump automatically activates and controls the
pump while showering. A hinged grate in the
oor provides access to clean and service the
sump system.
Chapter 12:
Head and Vanity with Shower Seat Down
INTERIOR EQUIPMENT
Head Compartment
