Exploded Diagram Parts List
Part Description Qty Part Description Qty
1 Rear Base Frame 1 36 Lower Cable (Length: 3840 mm) 1
2 Front Base Frame 1 37 Buttery Cable (Length: 2750 mm) 1
3 Weight Guide Tube 2 38 Oil Bushing (Small) 2
4 Front Support Frame 1 39 Oil Bushing (Big) 4
5 Selector Shaft 1 40 Select Shaft End Cap 1
6 Leg Extension Frame 1 41 Wrench 1
7 Seat Base Frame I 42 Chain (Length: 265 mm ) 1
8 Support Frame 1 43 Bumper 1
9 Upper Cross Beam 1 44 Selector Shaft Bushing 1
10 Press Bar 1 45 Round Cap (ø25mm) 1
11 Left Buttery Arm 1 46 Handle Grip 6
12 Right Buttery Arm 1 47 Square End Cap (☐38mm) 8
13 Pulley U 1 48 Square End Cap (☐40mm) 2
14 Single Pulley Block 2 49 Square Cap (☐38mm) 3
15 Reverse U I 50 Square End Cap (☐20x40mm) 2
16 Lat Bar I 51 Middle-empty Cap (☐38 x ø26) 2
17 Foam Tube 2 52 Round End Cap (ø25mm) 4
18 Handle Tube 2 53 Plastic Cover 2
19 Tobacco-pipe 1 54 Hex Bolt (M12x120mm) 1
20 Pothook 2 55 Hex Bolt (M10x65mm) 2
21 Weight Selector Pin 1 56 Hex Bolt (M10x60mm) 11
22 Rubber Ring 2 57 Hex Bolt (M10x45mm) 11
23 Top Weight Plate 1 58 Hex Bolt (M10x20mm) 2
24 Weight Plate (10LB) 7 59 Hex Bolt (M8x50mm) 2
25 Weight Plate (15LB) 2 60 Hex Bolt (M8x40mm) 2
26 Plastic Washer 1 61 Hex Bolt (M8x25mm) 1
27 Selector Shaft Pin 1 62 Hex Bolt (M8x15mm) 4
28 Seat Cushion 1 63 Washer (M12) 4
29 Back Cushion 1 64 Washer (M10) 50
30 Leg Foam Roller 4 65 Washer (M8) 12
31 Arm Foam Roller 2 66 Nylock Nut (M12) 3
32 Pulley (3.5”) 10 67 Nylock Nut (M10) 24
33 Big Pulley (4”) 1 68 Nylock Nut (M8) 3
34 Plum Blossom Nut 1 69 Bolt (M10x25mm) 4
35 Upper Cable (Length: 2310 mm) 1 70 Washer (ø30xø10.4) 1
