Everlast EV500 - Components - Parts

0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Ruler - Use this ruler to help correctly identify the hardware
Note: Cut out this page to help fixing identification during assembly.
3
Note: Some of the smaller components may be pre-fitted to larger components. Please check carefully
before contacting Argos regarding any missing components.
Please check you have all the parts listed below
Components - Parts
If you have damaged or missing components,
call the Customer Helpline: 0845 6000 464
1. Rear Base Frame x 1 2. Front Base Frame x 1 3. Weight Guide Tube x 2
4. Front Support Frame x 1 5. Selector Shaft x 1 6. Leg Extrension Frame x 1
7. Seat Base Frame x 1 8. Support Frame x 1 9. Upper Cross Beam x 1
10. Press Bar x 1 11. Left Butteryy Arm x 1 12. Right Butteryy Arm x 1
23. Top Weight Plate x 1 24. Weight Plate (10LB) x 7 25. Weight Plate (15LB) x 2
28. Seat Cushion x 1 29. Back Cushion x 1
