0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Ruler - Use this ruler to help correctly identify the hardware
Note: Cut out this page to help fixing identification during assembly.
5
Components - Fixings
Note: Some of the fixings are pre-fitted to the larger components. Please check carefully before contacting
Argos regarding any missing fixings.
Please check you have all the fixings listed below
45
25mm Round Cap x 1
46
Handle Grip x 6
47
38mm Square End Cap x 8
48
40mm Square End Cap x 2
49
38mm Square Cap x 3
50
20x40mm Square End Cap x 2
51
☐38xø2 Middle-empty Cap x 2
52
25mm Round End Cap x 4
53
Plastic Cover x 2
54
M12x120mm Hex Bolt x 1
55
M10x65mm Hex Bolt x 2
56
M10x60mm Hex Bolt x 11
57
M10x45mm Hex Bolt x 11
58
M10x20mm Hex Bolt x 2
59
M8x50mm Hex Bolt x 2
60
M8x40mm Hex Bolt x 2
61
M8x25mm Hex Bolt x 1
62
M8x15mm Hex Bolt x 4
63
M12 Washer x 4
64
M10 Washer x 50
65
M8 Washer x 12
66
M12 Nylock Nut x 3
67
M10 Nylock Nut x 24
68
M8 Nylock Nut x 3
69
M10x25mm Bolt x 4
70
ø30xø10.4 Washer x 1
To Next Page
