Application Note 65
Quartz Routing Switcher Remote Control Protocol
Page - 20 Revision 1.4
6. EXAMPLES
Note that (cr) = ASCII carriage return (code 0D hex).
From Computer
From Router
Description
(cr).P(cr)
power on or reset
.SV003,001(cr)
.UV003,001(cr)
set dest-3 to srce-1 on level-1
.SV3,1(cr)
.UV003,001(cr)
set dest-3 to srce-1 on level-1
.SVAB02,001(cr)
.UVAB002,001(cr)
set dest-2 to srce-1 on levels-1,2,3
.SZ1,3(cr)
.E(cr)
level Z not allowed
.SB45,12
.E(cr)
dest to large
.IV1(cr)
.AV001,001(cr)
get status of level-1 dest-1
.IA3(cr)
.AA003,002(cr)
get status of level-2, dest-3
.IVABC9(cr)
.E(cr)
only one level can be interrogated
.LV5,-(cr)
.AV005,002V006,009V007,010V008,
031V009,001V010,001V011,017V01
2,003(cr)
get status of level-1 dest-5 to dest-12
.LB1,1(cr)
.AB001,001B007,001B(cr)
only dest-1 and dest-7 using srce-1
.UV007,003(cr)
system change by a control panel or
another computer interface
.#01(cr)
.A(cr)
check to see if router connected
.?0C40(cr)
.A0C40,02,34,7F,2D,20,20,20,0D(cr)
read of system setup data
.!328E,01,02,56,7F(cr)
.A328E,01,02,56,7F (cr)
write of system setup data
