Application Note 65
Quartz Routing Switcher Remote Control Protocol
Revision 1.4 Page - 1
1. INTRODUCTION
This document specifies a protocol suitable for simple control of a Quartz routing system by a
computer or third party system. The protocol can use any of the physical interfaces available on the
system, either a RS232/422 interface or Ethernet.
As the protocol is ASCII text based, remote changes can be made using a terminal or a computer
running terminal emulation software. For most applications only the .S command will be required to set
crosspoints, with the .I or .L command to interrogate crosspoints. The .#01 command may be used at
system start up to check the RS232/422 link.
1.1. SERIAL (RS232 / 422) PHYSICAL INTERFACE
Most Quartz products have a built in serial port that is link selectable between RS422 and RS232 mode.
For older routing products see the section at the end of this document.
1.1.1. Quartz D9 Serial Pin-Out
The full router pin-out is shown below:
RS232 RS422
2 RTS 2 TX-
3 RXD 3 RX+
4 N/C 4 RX GND
5 N/C 5 N/C
6 GND 6 TX GND
7 TXD 7 TX+
8 CTS 8 RX-
9 N/C 9 N/C
