202
POWERHEAD
POWERHEAD REMOVAL
POWERHEAD REMOVAL
Remove lower motor covers. Lower Cover
Removal on p. 82.
Disconnect power trim connectors.
Remove pin and washer from shift rod lever to
release the lower shift rod.
Remove six retaining screws and exhaust relief
muffler.
Install Lifting Fixture, P/N 396748, on flywheel and
seat the three screws completely.
IMPORTANT: Be sure to use only the 1 1/8 in.
(short) screws, P/N 398067, included with the tool
to avoid damage to electronic components under
the flywheel.
Fasten appropriate chain hook to eye of tool and
support weight of powerhead with hoist.
WARNING
Protect against hazardous fuel spray.
Before starting any fuel system service,
carefully relieve fuel system pressure.
Refer to Relieving Fuel System Pressure.
To prevent accidental starting while ser-
vicing, disconnect the battery cables at
the battery.
002152
1. Shift rod screw 002013
1
002159
1. Lifting fixture
2. 1 1/8 in. screws
002098
2
1
