Please note that if your host interface only has one optical
port per connection then you can use just one TOSlink cable
per connection. However, this will limit your channel count to 4
channels at 88.2 and 96 kHz .
EVO EXPANDED SYSTEM
Connect the Optical Outputs of the host interface to the Optical
Inputs of the EVO SP8 using two TOSlink cables.
Connect the Optical Inputs of the host Interface to the Optical
Outputs on SP8 using two further TOSlink cables.
Connect the Word Clock Output of the host interface to the Word
Clock Input of the SP8.
In the Setup Menu of the EVO SP8, ensure that your clock source is set
to ‘Word Clock’ and the Word Clock Termination is turned on. Also set
the Sample Rate to ‘Auto’.
On the Host Interface, ensure that its clock source is set to “Internal”
and the Optical format is set to ‘ADAT’.
