Evolution EvoSaw 230 - Tool Specifications; Cutting Capacity Details; Machine and Blade Specifications; Noise and Vibration Data

6
www.evolutionpowertools.com
SPECIFICATIONS
CUTTING CAPACITY METRIC IMPERIAL
Mild Steel Box Section (at 90
o
) 83mm 3-1/4”
Mild Steel Box Section (at 45
o
) 54mm 2-1/8”
Maximum Cutting Thickness (Mild Steel Plate) 12mm 1/2”
Maximum Wall Thickness (Box Section) 6mm 1/4”
MACHINE METRIC IMPERIAL
Motor (USA) 120v ~ 60Hz 1750W 15A
Motor (UK/EU) 230v ~ 50/60Hz 1750W 8A
Motor (UK) 110v ~ 50/60Hz 1750W 15A
Speed No Load 2700min
-1
2700rpm
Weight 8.6kg 19lbs
BLADE MILD STEEL BLADE METRIC IMPERIAL
Diameter 230mm 9”
Bore 25.4mm 1”
Number of Teeth (Supplied Blade) 48 48
Kerf 2mm .078”
Speed 3000min
-1
3000rpm
NOISE & VIBRATION DATA
Sound Pressure L
PA
(Under Load) 108.7dB(A) K=3dB(A)
Sound Power Level L
WA
(Under Load) 108.7dB(A) K=3dB(A)
Vibration Level (Under Load) 3.9m/s
2
K=1.5m/s
2
