Evolution R255SMS-DB User Manual

21
www.evolutionpowertools.com
Fig. 47 Fig. 49Fig. 48
R255SMS-DB
Standard Hold
Down Clamp
R255SMS-DB+
Quick Release
Hold Down Clamp
Fig. 46
1
2
3
4
5
6
7
8
9
1) Hex headed bolt
2) Spring washer
3) Flat washer
4) Mitre saw base
5) Workbench
6) Flat washer
7) Spring washer
8) Hex nut
9) Lock nut
Fig. 50
Fig. 44
Fig. 51
FRONT CLAMP
SOCKET
FRONT CLAMP
SOCKET
Fig. 52
Fig. 42 Fig. 43
Fig. 45
a.
b.
EN
