Evolution R255SMS-DB User Manual

UK/EU/AU
MACHINE SPECIFICATION R225SMSDB R225SMSDB+
Model No:
053-0001,053-0002,
053-0003
053-0001A, 053-0002A,
053-0003A, 053-0011
Motor (220-240V ~ 50 Hz) 2000W 2000W
Motor (110V ~ 50 Hz) 1600W 1600W
Speed No Load 2600 min
-1
2600 min
-1
Weight (Net) 16.5kg 18.3kg
Dust Port Diameter 35mm 35mm
Cable Length 3m 4m
CUTTING CAPACITIES R225SMSDB R225SMSDB+
Mild Steel Plate - Max Thickness 6mm 6mm
Mild Steel Box Section - Max Wall Thickness
(50mm mild steel box section.)
3mm 3mm
Wood – Max section 300 x 80 mm 300 x 90 mm
MITRE BEVEL R225SMSDB R225SMSDB+
0° 0° 300mm x 80mm 300mm x 90mm
0° 45° Left 300mm x 46mm 300mm x 52mm
0° 45° Right 300mm x 27mm 300mm x 34mm
45° 0° 212mm x 80mm 212mm x 90mm
45° 45° Left 212mm x 46mm 212mm x 52mm
45° 45° Right 212mm x 27mm 212mm x 34mm
45˚ 0˚ 212mm x 80mm 212mm x 90mm
BLADE SPECIFICATION R225SMSDB R225SMSDB+
Diameter 255mm 255mm
Number Of Teeth 24 28
Bore 25.4mm 25.4mm
Kerf 2mm 2mm
LASER
Laser Class Class 2
Laser Source Laser Diode
Laser Output Power (Max) ≤1mW
Wave Length (Nm) 650
NOISE EMISSION DATA*
Sound Pressure L
PA
(No-Load) 110V: 96,4 dB(A) / 220-240V~ 96,9 dB(A)
Sound Power Level L
WA
(No-Load) 110V: 109,4 dB(A) / 220-240V~ 109,9 dB(A)
Uncertainty, K
pA
& K
WA
K=3 dB(A)
*Noise emission test according to EN 62841-1 & EN 62841-3-9.
WARNING: The noise emissions during actual
use of the power tool can differ from the declared
values depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: The need to identify safety measures
to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
4
