NORTH AMERICA
MACHINE SPECIFICATION R225SMSDB R225SMSDB+
Model No: 053-0004 053-0004A
Motor (120V ~ 60 Hz) 15A 15A
Speed No Load 2600 rpm 2600 rpm
Weight (Net) 36.3lb 40.3lb
Dust Port Diameter 1 -3/8 In 1 -3/8 In
Cable Length 10ft 13ft
CUTTING CAPACITIES R225SMSDB R225SMSDB+
Mild Steel Plate - Max Thickness 1/4 In 1/4 In
Mild Steel Box Section - Max Wall Thickness
(2 in. mild steel box section.)
1/8 In 1/8 In
Wood – Max section 11-3/4 In x 3-1/2 In 11-3/4 In x 3-1/2 In
MITER BEVEL R225SMSDB R225SMSDB+
12 In x 3-1/8 In 12 In x 3-1/2 In
45° Left 12 In x 1-7/8 In 12 In x 2-1/16 In
45° Right 12 In x 1 In 12 In x 1-1/4 In
45° 8-3/8 In x 3-1/8 In 8-3/8 In x 3-1/3 In
45° 45° Left 8-3/8 In x 1-7/8 In 8-3/8 In x 2-1/16 In
45° 45° Right 8-3/8 In x 1 In 8-3/8 In x 1-1/4 In
45˚ 8-3/8 In x 3-1/8 In 8-3/8 In x 3-1/2 In
BLADE DIMENSIONS R225SMSDB R225SMSDB+
Diameter 10 In 10 In
Number Of Teeth 24 28
Bore 1 In 1 In
Kerf 5/64 In 5/64 In
LASER
Laser Class Class 2
Laser Source Laser Diode
Laser Output Power (Max) ≤1mW
Wave Length (Nm) 650
NOISE EMISSION DATA*
Sound Pressure L
PA
(No-Load) 110V: 95,8 dB(A) / 220-240V~ 95,8 dB(A)
Sound Power Level L
WA
(No-Load) 110V: 108,8 dB(A) / 220-240V~ 108,8 dB(A)
Uncertainty, K
pA
& K
WA
K=3 dB(A)
*Noise emission test according to EN 62841-1 & EN 62841-3-9.
5
www.evolutionpowertools.com
