22. ON / OFF TRIGGER SWITCH
23. LASER GUIDE ON / OFF SWITCH
24. DUST EXTRACTION PORT
25. CABLE
26. CUTTING HEAD LOCKING PIN
27. REAR SLIDING CARRIAGE
28. CABLE GUIDE CLAMP
29. BEVEL LOCK HANDLE
30. 33.9˚ BEVEL PIN
31. M4 SELF TAPPING CAP SCREW x1
32. M4 SOCKET HEAD SCREW x4
33. CABLE GRIP COMPONENT (FITTED TO THE
CABLE GUIDE CLAMP)
34. ANTI-VIBRATION SPRING (FITTED TO THE
ANTI-VIBRATION DEVICE)
