Evolution R255SMS - Machine Overview

1. CUTTING HANDLE
2. BLADE GUARD LOCKING LEVER
3. DUST BAG*
4. SLIDE LOCKING SCREW
5. DEPTH GAUGE
6. HOLD DOWN CLAMP
7. SLIDING FENCE
8. MACHINE TABLE EXTENSIONS
9. MOUNTING HOLE (X4)
10. FRONT CLAMP MOUNTING HOLES (X2)
11. BLADE ROTATION INDICATION ARROW
12. UPPER BLADE GUARD
13. CUTTING HEAD
14. BLADE
15. LOWER BLADE GUARD
16. TABLE TOP
17. ROTARY TABLE
18. TABLE INSERT
19. MITRE HANDLE LOCKING KNOB
20. POSITIVE STOP LOCKING LEVER
21. MITRE ANGLE SCALE
*Supplied as original equipment on the R255SMS+.
2
3
16
17
1
20
21
18
19
5
4
8
7
6
10
9
12
13
14
15
MACHINE OVERVIEW
11
14
