Evolution S355 MCS User Manual

12
www.evolutionpowertools.com
MACHINE OVERVIEW
1. LOWER BLADE GUARD
2. UPPER BLADE GUARD
3. CLAMP CROSS BAR
4. FRONT CLAMP X2
5. TOP CLAMP
6. TOP CLAMP QUICK RELEASE BUTTON
7. CUTTING HANDLE
8. CUTTING HEAD HOLD DOWN PIN
9. MITRE ANGLE SCALE
10. WORK BENCH MOUNTING HOLES X4
11. BLADE ARBOR GUARD
12. MITRE LOCKING KNOB
13. MITRE INDEX PUSH BUTTON
14. CARBON BRUSHES ACCESS CAP
15. ARBOR LOCK BUTTON
1
2
5
6
3
4
7
8
9
13
14
12
11
10
15

Evolution S355 MCS Specifications

General

Brand	Evolution
Model	S355 MCS
Category	Saw
Language	English
