6
www.evolutionpowertools.com
SPECIFICATIONS S355MCS
MACHINE UK/EU USA
Product code
UK 220-240V:102-0001,
UK 110V:102-0002,
EU 220-240V:102-0003
UK 120V:102-0004
Motor (UK/EU) 220V-240V ~ 50Hz 2200W -
Motor (UK) 110V ~ 50Hz 1600W -
Motor (USA) 120V ~ 60Hz - 15A
Speed (No Load) 1550 min
-1
1450 min
-1
Weight (With Blade) 35kg
Power Cord 3 m 10 feet
CUTTING CAPACITY
Mild Steel Plate (Max. Thickness) 12 mm 1/2 ”
Stainless Steel Plate (Max. Thickness)
5 mm ◊ 13/64 ” ◊
Square Tube at 90˚ 120 x 120mm 4-3/4” x 4-3/4”
Square Tube at 45˚ 100 x 100mm 3-29/32” x 3-29/32”
Rectangle Tube at 90° 100 x 165mm 3-29/32” x 6-7/16”
Rectangle Tube at 45° 100 x 110mm 3-29/32” x 4-3/8”
Round Tube at 90° Ø 120mm Ø 4-11/16”
Round Tube at 45° Ø 110mm Ø 4-5/16”
Minimum Cut Off Piece Length 8 mm 5/16 ”
BLADE
Diameter 355mm 14”
Bore 25.4mm 1”
Kerf 2.4 mm .094”
Mild Steel Blade No. Teeth 66
NOISE EMISSION DATA*
Sound Pressure Level L
PA
110V: 94,9 dB(A) / 220-240V: 94,8 dB(A)
Sound Power Level L
WA
110V: 107,9 dB(A) / 220-240V: 107,8 dB(A)
Uncertainty,
K
pA
& K
WA
3dB(A)
◊ Stainless Steel blade must be fitted.
WARNING: Due to the power input of this product on start up, voltage drops may occur and this can influence other
equipment (e.g. dimming lights). So for technical reasons we advise, if the mains-impedance is Zmax< 0.069Ω, these
disturbances are not expected. If you require further clarification, you may contact your local power supply authority.
