S355CPSL MACHINE OVERVIEW
1. LOWER BLADE GUARD
2. UPPER BLADE GUARD
3. FRONT SWIVELLING VICE JAW
4. REPOSITIONABLE REAR VICE JAW
5. CUTTING HANDLE
6. CUTTING HEAD HOLD DOWN PIN
7. REAR VICE JAW LOCKING LEVER
8. TRAVEL STOP ADJUSTMENT SCREW
9. PROTRACTOR SCALE
10. WORK BENCH MOUNTING HOLES X4
11. BLADE CHANGE HEX KEY
12. BLADE ARBOR GUARD
13. ARBOR LOCK BUTTON
14. VICE HANDLE
15. SHIELD
16. CARBON BRUSHES ACCESS CAP
17. ON/OFF TRIGGER SWITCH
18. CARRY HANDLE
2
1
6
17
15
9
3
10
14
5
4
7
16
12
18
8
11
13
