5
www.evolutionpowertools.com
EN
SPECIFICATIONS S355CPSL
MACHINE METRIC IMPERIAL
Motor (UK/EU) 220V-240V ~ 50Hz -
Motor (UK) 110V ~ 50Hz -
Motor (USA) 120V ~ 60Hz 15A
Motor (AUS) 240V ~ 50Hz -
Speed (No Load) @ 110V - -
Speed (No Load) @ 120V 1450 min
-1
1450 rpm
Speed (No Load) @ 220-240V - -
Weight (With Blade) 23.1 kg 51 lbs
Power Cord 3 m 10 feet
CUTTING CAPACITY
Mild Steel Plate (Max. Thickness) 6mm 1/4”
Stainless Steel Plate (Max. Thickness)
5mm ◊ 13/64” ◊
Square Tube at 90˚ 120 x 120mm 4-3/4 x 4-3/4”
Square Tube at 45˚ 89 x 89mm 3-1/2 “ x 3-1/2”
Rectangle Tube at 90° 95 x 180mm 3-3/4 x 7-1/8”
Rectangle Tube at 45° 78 x 95mm 3-1/8” x 4-3/8”
Round Tube at 90° Ø 130mm Ø 5-1/8”
Round Tube at 45° Ø 105mm Ø 4-1/8”
Minimum Cut Off Piece Length 8mm 5/16”
BLADE
Diameter 355mm 14”
Bore 25.4mm 1”
Kerf 3.2mm 0-1/8”
Mild Steel Blade No. Teeth 66
NOISE EMISSION DATA*
Sound Pressure Level L
PA
120V: 94,9 dB(A)
Sound Power Level L
WA
120V: 107,9 dB(A)
MODELS
United Kingdom -
United States (120V) 083-0010
Europe -
Australia -
◊ Stainless Steel blade must be fitted.
WARNING: Due to the power input of this product on start up, voltage drops may occur and this can influence other
equipment (e.g. dimming lights). So for technical reasons we advise, if the mains-impedance is Zmax< 0.069Ω, these
disturbances are not expected. If you require further clarification, you may contact your local power supply authority.
