Evolution S355CPSL User Manual

6
www.evolutionpowertools.com
SPECIFICATIONS S355CPS S380CPS *
MACHINE METRIC IMPERIAL METRIC IMPERIAL
Motor (UK/EU) 220V-240V ~ 50Hz 2200 W -
Motor (UK) 110V ~ 50Hz 1600 W -
Motor (USA) 120V ~ 60Hz - 15 A
Motor (AUS) 240V ~ 50Hz 2200 W -
Speed (No Load) @ 110V 1550 min
-1
1550 rpm - -
Speed (No Load) @ 120V - - 1450 min
-1
1450 rpm
Speed (No Load) @ 220-240V 1550 min
-1
1550 rpm - -
Weight (With Blade) 23 kg 53 lbs 23 kg 53 lbs
Power Cord 3 m 10 feet 3 m 10 feet
CUTTING CAPACITY
Mild Steel Plate (Max. Thickness) 6 mm 1/4 ” 6 mm 1/4 ”
Stainless Steel Plate (Max. Thickness) 5 mm ◊ 13/64 ” ◊ 5 mm ◊ 13/64 ” ◊
Square Tube at 90˚ 120 x 120mm 4-3/4” x 4-3/4” 120 x 120mm 4-3/4” x 4-3/4”
Square Tube at 45˚ 89 x 89mm 3-1/2” x 3-1/2” 89 x 89mm 3-1/2” x 3-1/2”
Rectangle Tube at 90° 95 x 180mm 3-3/4” x 7-1/8” 95 x 180mm 3-3/4” x 7-1/8”
Rectangle Tube at 45° 78 x 110mm 3-1/8” x 4-3/8” 78 x 110mm 3-1/8” x 4-3/8”
Round Tube at 90° Ø 130mm Ø 5-1/8” Ø 130mm Ø 5-1/8”
Round Tube at 45° Ø 105mm Ø 4-1/8” Ø 105mm Ø 4-1/8”
Minimum Cut Off Piece Length 8 mm 5/16 ” 8 mm 5/16 ”
BLADES
Diameter 355 mm 14 ” 355 mm 14”
Bore 25.4 mm 1 ” 25.4 mm 1”
Kerf 2.4 mm .094” 2.4 mm .094”
Mild Steel Blade No. Teeth 66 66
Stainless Steel Blade No. Teeth
(Supplied on AUS model only)
90 N/A
NOISE EMISSION DATA
Sound Pressure Level L
PA
110V: 94,9 dB(A) / 220-240V: 94,8 dB(A) 120V: 94,9 dB(A)
Sound Power Level L
WA
110V: 107,9 dB(A) / 220-240V: 107,8 dB(A) 120V: 107,9 dB(A)
MODELS
United Kingdom (230V) 084-0001, (110v) 084-0002 -
United States - (120V) 084-0004
Europe (230V) 084-0003 -
Australia (230V) 084-0006 -
◊ Stainless Steel blade must be fitted.
* Supplied with a 14” (355mm) blade. Capable of fitting a 15” (380mm) steel cutting blade.
WARNING: Due to the power input of this product on start up, voltage drops may occur and this can influence other
equipment (e.g. dimming lights). So for technical reasons we advise, if the mains-impedance is Zmax< 0.069Ω, these
disturbances are not expected. If you require further clarification, you may contact your local power supply authority.

Evolution S355CPSL Specifications

General

Brand	Evolution
Model	S355CPSL
Category	Saw
Language	English
