EXCELL PRECISION CO., LTD
3-6 Linearity calibration
Before the Linearity calibration, the General calibration should be completed.
Set CAL switch to ON
Select linearity calibration
Press the key
Select one of five calibration, and
Press the key
Press the key
When stable, the display area shows
the modified weight value
Please refer to the error message list if the display shows . X .
Increment flashing digit
Decrement flashing digit
Move flashing point left.
Move flashing point right
Store data in memory
Exit / Escape
Use to select one of
calibration points (1P~5P)
: no setting value
: with setting value
Key in the correct weight value
Finish the 1
st
calibration point
setting. Either continues the
second point calibration or
press key to exit the
linearity calibration process
To Next Page
