040112XX
EXCELL PRECISION CO., LTD
ZSME400000005
41
10
1
5
4
3
2
9
8
7
6
CAL
13
12
11
RS-232
1.TxD
3.RxD
6.SG
2
3
4
5
1
RS-422/485
5.TRM
6.SG
6
2.SDB
4.RDB
3.RDA
1.SDA
ON
RS1- 07
Indicator poling address
00
99
When set to 0, Indicator addressing is not
used
1
2. OP-01 RS-422 / RS-485 / RS-232
PIN
Function
RS422/RS485
RS232
1
SDA
TXD
2
SDB
3
RDA
RXD
4
RDB
5
TRM
6
SG
SG
Jumper configuration
Second serial port interface setting procedure
Press key
Press key
Input desired
parameter code
Press key
Display show the existing
parameter code. Input a new
code as required
Continue to the next function setting or
press key to escape
J1
J2
J3
J4
1
2
3
J6
1
J5
2
3
J5-J6
1-2 short RS422
2-3 short RS485
J1-J4
1-2 short RS422/485
2-3 short RS232
