Exerpeutic EXERWORK 2000i - Seat Assembly

13
ASSEMBL
Y
STEP 3
3A. Installing the Seat Post
Insert the Seat Post (10) into the Front Frame (2). Tighten the Seat Post (10) with the Seat
Adjustment Knob (14).
STEP 4
4A. Installing the Seat to the Seat Bracket
Attach the Seat (6) onto the Seat Bracket (5) using three Hexagon Socket Bolts (58), three
Spring Washers (102), and three Flat Washers (33). Tighten the Hexagon Socket Bolts (58)
with the 5mm Allen Wrench with Phillips Screwdriver provided.
HARDWARE PACK
(58) Hexagon Socket Bolt
3 PCS
(33) Flat Washer
3 PCS
(102) Spring Washer
3 PCS
5mm Allen Wrench
With Phillips Screwdriver
1 PC
TOOLS
