14
ASSEMBL
Y

STEP 5
5A. Installing the Seat Bracket to the Seat Post
Place the Seat Bracket (5) into the top slot of the Seat Post (10). Insert one Socket Hexagon
Bolt (79) through the hole located on the side of the Seat Bracket (5) and Seat Post (10). Attach
one Flat Washer (33), and one Nylon Nut (34). Tighten the hardware with the 5mm Allen
Wrench with Phillips Screwdriver and 13-15mm Wrench provided.
5B. Installing the Seat Post Knob to the Seat Post
Insert one U-Bracket (108), one Washer (83), and one Knob (82) into slot on the underside of the
Seat Post (10). The Knob (82) should be inserted into the threaded shaft of the Seat Bracket (5)
which is now inside the Seat Post (10).
5mm Allen Wrench
With Phillips Screwdriver
1 PC
TOOLS
13-15mm Wrench 1 PC
HARDWARE PAC
K
(79) Hexagon Socket Bolt
1PC
(34) Nylon Nut
1 PC
(33) Flat Washer
1 PCS
(83) Washer 1PC
