Exerpeutic WorkFit - Component Parts List

Part # Description Qty Part # Description Qty
1 Rear Frame 1 36 Washer Ø6.2 2
2 Front Frame 1 37 Sensor with Wire 1
3 Rear Stabilizer 1 38 Flywheel Ø195 1
4 Handlebar 1 39
Belt Wheel with Crank Axle
Ø155
1
5 Seat Post 1 40 Bearing Bracket 2
6 Seat 1 41 Wave Washer 1
7 Left Pedal 1 42 Bearing 6003RS 4
7-1 Left Pedal Strap 1 43 C-ring Ø17 6
8 Right Pedal 1 44
Belt Wheel with Crank Axle
Ø150
1
8-1 Right Pedal Strap 1 45 Bearing 6000z 2
9 Backrest Frame 1 46 Axle Ø12.8x94L 1
10 Wire Plug 2 47 Eyebolt M6 2
11 Rear Stabilizer End Cap 2 48 Tension Bracket 2
12 Seat Post Plastic Bushing 1 49 Backrest 1
13 Tension Control Knob 1 50 Nylon Nut M6 2
14 Adjustment Knob M16 1 51 Nut M10 2
15 Rear Supporting Tube 1 52 Washer Ø10.2xØ25 1
16 Oval Wire Plug 5 53 Wave Washer Ø17 1
17 Handrail Foam Grip 2 54 Idle Wheel Axle 1
18 Left Cover 1 55 Nylon Nut M10 1
19 Right Cover 1 56 Bearing 6902Z 2
20 Top Shroud 1 57 Axle 1
21 Round Plastic Bushing 6 58 Hexagon Socket Bolt M8*15 5
22 Safety Pin Ø10*110L 1 59 Rubber Cushion 1
23 Left Crank 1 60 Washer Ø8.2x Ø25x2.0t 2
24 Right Crank 1 61 Flat Phillips Head Screw M6x10 6
25 France Nut 2 62 Holder 1
26 Crank Cover 2 63
Round Phillips Head Screw
M4x10
1
27
Round Phillips Head Drilling
Screw M4x20
4 64 Plastic Washer 1
28
Round Phillips Head Tapping
Screw M4x20
5 65 C-ring Ø15 1
29 Hexagon Cap Nut M8 5 66 Square end cap 4
30 Curve Washer D Ø8.2 6 67 Rear Frame Support Tube 1
31 Front Stabilizer 1 68 Screw M5x20 1
32 C-ring Ø 10 2 69 Washer Ø5.2xØ18 2
33 Flat Washer Ø8.2 13 70 Spring 1
34 Nylon Nut M8 6 71 Belt 240J4 1
35 Magnet Bracket 1 72 Belt 230J3 1
6
PARTS LIST
