ProductOverview
Setup
UnfoldingtheHandle
1.Raisethehandletotheoperatingposition.
g013073
1
Figure3
1.Ovallockingring
2.Slidetheovallockingringsdowneachsideofthe
upperhandleoverthelowerhandle,lockingthe
handlesectionstogether.
ProductOverview
Figure4
1.Tinegroundengagement
lever
4.Fuelcap
2.Self-propeldrivebail
5.Recoilstarter
3.Handle
14
